Genebre Fig: 2274 - 1-1/4" BSP - Range 0.5 to 12 Bar Pilot operated Pressure Reducing Valve.
1-1/4" 32mm. Threaded ends acc. to ISO 7-1, Construction: Carbon steel 1.0619 (WCB). Maximum input pressure 25 bar. Outlet pressure from 0,5 to 12 bar. Maximum working temperature 260ºC. (Steam or compressed air applications)
1,804.04 € 1804.04 EUR
Genebre Fig: 2274 - 1" BSP - Range 0.5 to 12 Bar Pilot operated Pressure Reducing Valve.
1". Threaded ends acc. to ISO 7-1, Construction: Carbon steel 1.0619 (WCB). Maximum input pressure 25 bar. Outlet pressure from 0,5 to 12 bar. Maximum working temperature 260ºC. (Steam or compressed air applications)
1,613.63 € 1613.63 EUR
Genebre 1/2" BSP Fig: 2281 Pressure Reducing Valve.
Threaded ends acc. to ISO 7-1. acc. to ISO 7-1. Construction: stainless steel CF8 (304). Maximum input pressure 16 bar. Outlet pressure from 2 to 8 bar. Maximum working temperature 200ºC. (Steam application)
356.69 € 356.69 EUR
Genebre 3/4" BSP Fig: 2281 Pressure Reducing Valve.
Threaded ends acc. to ISO 7-1. acc. to ISO 7-1. Construction: stainless steel CF8 (304). Maximum input pressure 16 bar. Outlet pressure from 2 to 8 bar. Maximum working temperature 200ºC. (Steam application)
370.08 € 370.08 EUR
Genebre 1" BSP Fig: 2281 Pressure Reducing Valve.
Threaded ends acc. to ISO 7-1. Construction: stainless steel CF8 (304). Maximum input pressure 16 bar. Outlet pressure from 2 to 8 bar. Maximum working temperature 200ºC. (Steam application)
418.53 € 418.53000000000003 EUR
ADCA CTS4U 3/4" - DN20 BSP, ISO 7Rp, Compact Trapping Station
The UniADCA CTS4U is a complete and compact steam trapping station designed to be used as an alternative to traditional multicomponent trap stations, simplifying maintenance and reducing downtime and associated costs. The swivel connector allows steam trap replacement in only a few minutes without disturbing the pipeline. Compatible with “two-bolt” UniADCA universal steam traps and other universal steam traps with swivel connector. Typical installations include drip service on steam lines, tracing, SKID’s and small process equipment.

MAIN FEATURES Depending on variant.
Built-in strainer and check valve. Reduced downtime and costs due to easy in-line maintenance. Safe depressurization through bleed valve or BDV. Available with double upstream shut-off valves. Universal steam traps can swivel 360°, allowing the steam trap to be fitted in the correct position, regardless of pipeline configuration.
ADCA CTS4U 1/2" - DN15 BSP, ISO 7Rp, Compact Trapping Station
The UniADCA CTS4U is a complete and compact steam trapping station designed to be used as an alternative to traditional multicomponent trap stations, simplifying maintenance and reducing downtime and associated costs. The swivel connector allows steam trap replacement in only a few minutes without disturbing the pipeline. Compatible with “two-bolt” UniADCA universal steam traps and other universal steam traps with swivel connector. Typical installations include drip service on steam lines, tracing, SKID’s and small process equipment.

MAIN FEATURES Depending on variant.
Built-in strainer and check valve. Reduced downtime and costs due to easy in-line maintenance. Safe depressurization through bleed valve or BDV. Available with double upstream shut-off valves. Universal steam traps can swivel 360°, allowing the steam trap to be fitted in the correct position, regardless of pipeline configuration.
Genebre Fig: 2274 - 3/4" BSP - Range 0.5 to 12 Bar Pilot operated Pressure Reducing Valve.
3/4". Threaded ends acc. to ISO 7-1, Construction: Carbon steel 1.0619 (WCB). Maximum input pressure 25 bar. Outlet pressure from 0,5 to 12 bar. Maximum working temperature 260ºC. (Steam or compressed air applications)
1,533.94 € 1533.94 EUR
Genebre Fig: 2274 - 1/2" BSP - Range 0.5 to 12 Bar Pilot-operated Pressure Reducing Valve.
1/2". Threaded ends acc. to ISO 7-1, Construction: Carbon steel 1.0619 (WCB). Maximum input pressure 25 bar. Outlet pressure from 0,5 to 12 bar. Maximum working temperature 260ºC. (Steam or compressed air applications)
1,444.30 € 1444.3 EUR
DN 20 TF-GLV-800-G CARBON STEEL GLOBE VALVE Socket Weld A105N / A410 800lbs TRIM. Socket welding ends according to ISO 15761
APPLICATION :
Nafta, steam, petrochemical, petroleum, high pressure.
GENERAL CHARACTERISTICS :
Rising rotating stem OS&Y
Bolted bonnet.
Metal-metal seat F6+XU Respect the flow direction indicated by the arrow. Standard Port
Class 800 lbs.
STANDARDS :
Manufacture according to ISO 9001 : 2008
Directive 2014/68/EU: CE Nº 0036 Risk Category III module H
ressure Tests according to API 598 Table 6
BSP Conical according to ISO 7-1 Rc
NPT according to ANSI B1.20.1
Socket welding ends according to ISO 15761
Designed according to ISO 15761 and API 602 8th
ATEX Group II Category 2G/2D zone 1&21 zone 2&22 according to directive 2014/34/EU Optional marking.
WORKING CONDITIONS :
Maximum Working Pressure : 136 bar.
Maximum Working Temperature : - 29 °C / + 425 °C.
87.00 € 87.0 EUR
